Amazon RDS and Amazon Virtual Private Cloud (VPC)

Yesterday I helped a friend to figure out why he couldn’t connect to his Amazon RDS database inside the Amazon VPC (Virtual Private Cloud).  It was the second time someone asked me to help with the Amazon Web Services (AWS), and it was the first time I was actually helpful.  Yey!

While I do use quite a few of the Amazon Web Services, I don’t have any experience with the Amazon RDS yet, as I’m managing my own MySQL instances.  It was interesting to get my toes wet in the troubleshooting.

Here are a few things I’ve learned in the process.

Lesson #1: Amazon supports two different ways of accessing the RDS service.  Make sure you know which one you are using and act accordingly.

gs-vpc-network

If you run an Amazon RDS instance in the VPC, you’ll have to setup your networking and security access properly.  This page – Connecting to a DB Instance Running the MySQL Database Engine – will only be useful once everything else is taken care of.  It’s not your first and only manual to visit.

Lesson #2 (sort of obvious): Make sure that both your Network ACL and Security Groups allow all the necessary traffic in and out.  Double-check the IP addresses in the rules.  Make sure you are not using a proxy server, when looking up your external IP address on WhatIsMyIP.com or similar.

Lesson #3: Do not use ICMP traffic (ping and such) as a troubleshooting tool.  It looks like Amazon RDS won’t be ping-able even if you allow it in your firewalls.  Try with “telnet your-rds-end-point-server your-rds-end-point-port” (example: “telnet 1.2.3.4 3306” or with a real database client, like the command-line MySQL one.

Lesson #4: Make sure your routing is setup properly.  Check that the subnet in which your RDS instance resides has the correct routing table attached to it, and that the routing table has the default gateway (0.0.0.0/0) route configured to either the Internet Gateway or to some sort of NAT.  Chances are your subnet is only dealing with private IP range and has no way of sending traffic outside.

Lesson #5: When confused, disoriented, and stuck, assume it’s not Amazon’s fault.  Keep calm and troubleshoot like any other remote connection issue.  Double-check your assumptions.

There’s probably lesson 6 somewhere there, about contacting support or something along those lines.  But in this particular case it didn’t get to that.  Amazon AWS support is excellent though.  I had to deal with those guys twice in the last two-something years, and they were awesome.

Taking the Pain Out of MySQL Schema Changes

Taking the Pain Out of MySQL Schema Changes” covers the following approaches to deploying MySQL schema changes:

  1. Schema Change in Downtime
  2. Role Swap (cluster setup)
  3. pt-online-schema-change

The last one is the usage of pt-online-schema-change tool developed by Percona guys, as part of their Percona Toolkit – an Open Source set of command-line tools for MySQL.

Database Engines Ranking

db-engines-ranking-table

DB-Engines.com provides some insight into some of the most popular database engines (312 of them to be precise).  Nothing too surprising there – Oracle and MySQL leading the charts, but it’s nice to have the numbers and trends.

db-engines-ranking

There are, of course, many different ways how the popularity can be calculated.  Their method is based on the popularity of each engine in a variety of online outlets, from Google Search to social networks.

  • Number of mentions of the system on websites, measured as number of results in search engines queries. At the moment, we use Google, Bing and Yandex for this measurement. In order to count only relevant results, we are searching for <system name> together with the term database, e.g. “Oracle” and “database”.
  • General interest in the system. For this measurement, we use the frequency of searches in Google Trends.
  • Frequency of technical discussions about the system. We use the number of related questions and the number of interested users on the well-known IT-related Q&A sites Stack Overflow and DBA Stack Exchange.
  • Number of job offers, in which the system is mentioned. We use the number of offers on the leading job search engines Indeed and Simply Hired.
  • Number of profiles in professional networks, in which the system is mentioned. We use the internationally most popular professional networks LinkedIn and Upwork.
  • Relevance in social networks. We count the number of Twitter tweets, in which the system is mentioned.

It seems objective and representative enough to me.

Fixing “InnoDB: Error: log file ./ib_logfile0 is of different size”

For the last few days I’ve been moving MySQL databases around at work.  Being a bit in a rush and overconfident (I have backups!),  I was simply detaching the /var/lib/mysql volume on one host (running Amazon AMI and MySQL) and attaching it to another host (running CentOS 7 and MariaDB).

It’s not surprising that I got this error: “InnoDB: Error: log file ./ib_logfile0 is of different size“.  Gladly, this ServerFault thread provided enough hints for me to solve the problem.  In a nutshell:

  1. Temporarily comment out the InnoDB log file size setting (e.g.: innodb_log_file_size = 64M) in /etc/my.cnf.
  2. Set innodb_fast_shutdown to 0 (read more).
  3. Restart the MySQL service once or twice.
  4. Uncomment the log file size setting.
  5. Set InnoDB fast shutdown back to default or remove it from your my.cnf altogether.
  6. Celebrate!

Knowing how little I learn from my own mistakes, I’m sure I’ll find this post useful in the future.

BitBucket Pipelines and Docker for PHP Developers

I’ve been meaning to look into Docker for a long while now.  But, as always, time is the issue.  In the last couple of days though I’ve been integrating BitBucket Pipelines into our workflow.  BitBucket Pipelines is a continuous integration solution, which runs your project tests in a Docker container.  So, naturally, I had to get a better idea of how the whole thing works.

Docker for PHP Developers” article was super useful.  Even though it wasn’t immediately applicable to BitBucket Pipelines, as they don’t currently support multiple containers – everything has to run within a single container.

The default BitBucket Pipelines configuration suggests the phpunit/phpunit image.  If you want to run PHPUnit tests only, that works fine.  But if you want to have a full blown Nginx and MySQL setup for extra bits (UI tests, integration tests, etc), then you might find smartapps/bitbucket-pipelines-php-mysql image much more useful.  Here’s the full bitbucket-pipelines.yml file that I’ve ended up with.

MySQL, PHP and “Integrity constraint violation: 1062 Duplicate entry”

Anna Filina blogs about an interesting problem she encountered with when working on a PHP and MySQL project:

MySQL was complaining about “Integrity constraint violation: 1062 Duplicate entry”. I had all the necessary safeguards in my code to prevent duplicates in tha column.

I gave up on logic and simply dumped the contents of the problematic column for every record. I found that there was a record with and without an accent on one of the characters. PHP saw each as a unique value, but MySQL did not make a distinction, which is why it complained about a duplicate value. It’s a good thing too, because based on my goal, these should have been treated as duplicates.

She also mentions two possible solutions to the problem:

My solution was to substitute accented characters before filtering duplicates in the code. This way, similar records were rejected before they were sent to the database.

and

As pointed out in the comments, a more robust and versatile solution would be to check the collation on the column.

I’m sure this will come in handy one day.

WWW SQL Designer

www sql designer

I came across the WWW SQL Designer today, and I have only one thing to say…

Holy Molly!  I’ve been looking for a tool like this for a long long time!  It is a web-based database designer, which can export designs into MySQL.  It’s super easy to use and it does exactly what it is supposed to.  No non-sense.  Simply amazing!

Cipherli.st – strong ciphers for Apache, Nginx and Lighttpd

Cipherli.st – provides ready to use cipher configurations for a variety of applications, such as Apache, Nginx, Lighttpd, HAProxy, Exim, Postfix, Dovecot, OpenSSH, and others.  This is a huge time-saver for those of us not well versed in cryptography and security.

Don’t forget to use Qyalis SSL Labs SSL Server Test tool for the complete analysis of where you went wrong.

WordPress Benchmark of MySQL server on Amazon EC2

I have a friend who is a newcomer to the world of WordPress.  Until recently, he was mostly working with custom-built systems and a PostgreSQL database engine, so there are many topics to cover.

One of the topics that came up today was the performance of the database engine.  A quick Google search brought up the Benchmark plugin, which we used to compare results from several servers.  (NOTE: you’ll need php-bcmath installed on your server for this plugin to work.)

My friend’s test server showed a rather poor 48 requests / second result.  And that’s on an Intel Core2 Duo E4500 machine with 4 GB of RAM and 160 GB 7200 RPM SATA HDD, running Ubuntu 12.04 x86-64.

So, I tried it on my setup.  My setup is all on Amazon EC2, using the smallest possible t2.micro servers (that’s Intel(R) Xeon(R) CPU E5-2670 v2 @ 2.50GHz, with 1 GB of RAM and god knows what kind of hard disk, running Amazon AMI).

First, I ran the benchmark on the test server, which hosts about 20 sites with low traffic (I didn’t want to bring up a separate instance for just a single benchmark run).  MySQL runs on the same instance as the web server.  And here are the results:

Your System Industry Average
CPU Speed: 38,825 BogoWips 24,896 BogoWips
Network Transfer Speed: 97.81 Mbps 11.11 Mbps
Database Queries per Second: 425 Queries/Sec 1,279 Queries/Sec

Secondly, I ran the benchmark on one of the live servers, which also hosts about 20 sites with low traffic. Here though, Nginx web server runs on one instance and the MySQL database on another. Here are the results:

Your System Industry Average
CPU Speed: 37,712 BogoWips 24,901 BogoWips
Network Transfer Speed: 133.91 Mbps 11.15 Mbps
Database Queries per Second: 1,338 Queries/Sec 1,279 Queries/Sec

In both cases, MySQL is v5.5.42, running on the /usr/share/doc/mysql55-server-5.5.42/my-huge.cnf configuration file. (I find it ironically pleasing that the tiniest of Amazon EC2 servers fits perfectly for the huge configuration shipped with documentation.)

The benchmark plugin explains how the numbers are calculated. Here’s what it says about the database queries:

To benchmark your database I use your wp_options table which uses the longtext column type which is the same type used by wp_posts. I do 1000 inserts of 50 paragraphs of text, then 1000 selects, 1000 updates and 1000 deletes. I use the time taken to calculate queries per second based on 4000 queries. This is a good indication of how fast your overall DB performance is in a worst case scenario when nothing is cached.

So, it’s a good number to throw around, but it’s far from the realistic site performance, as your WordPress site will mostly get SELECTs, not INSERTs or UPDATEs or DELETEs. And then, you’ll obviously need to see how many SQL queries do you need per page. And then you’ll need to examine all the caching in play – from browser, web server, WordPress, MySQL, and the operating system. And then, and then, and then.

But for a quick measure, I think, this is a good benchmark. It’s obvious that my friend can get a lot more out of his server without digging too deep. It’s obvious that separating web and database server into two Amazon instances gives you quite a boost. And it’s obvious that I don’t know much about performance measuring.

SchemaSpy – Graphical Database Schema Metadata Browser

SchemaSpy – Graphical Database Schema Metadata Browser.  This is a tool written in Java that helps one to generate database schema documentation.  Have a look at some sample pages.  Those familiar with Graphviz will immediately realize that the tools is using dot for graphing tables and their relationships.  Those familiar with SugarCRM documentation will immediately notice that SchemaSpy is used for the API documentation.
